600T Aluminium Extrusion Press -Thin Profile by High Output

Product Name:
600T Aluminium Extrusion Press -Thin Profile by High Output
Model No.:
600T

Product Abstract:

600T Aluminium Extrusion Press Make Thin Profile with High Output, low failure rate,

Product Description

600T Aluminium Extrusion Press-Make Small and Thin Aluminum Profile by High Output

With developing of aluminium extrusion industry, more and more aluminium extrusion manufacture produce the small and thin aluminium profile like the LED light cover, floor aluminium trim, stair aluminium trim, and cabinet aluminium trim and so on. Because these aluminum profiles no need to stand the force just for decorating, so the thinner, the better. We focus on aluminium extrusion press manufacture by lower failure rate, energy saving, faster extrusion speed, little butt of aluminum billet left, stable for central point, easy to operation and higher output production for increase client’s profit and boost their competitiveness.

One of our Chinese clients mainly produces 0.3mm~0.8mm aluminum profiles, one 600T aluminum extrusion press can produce around 2.5T~2.8T aluminum profile per 12 hours (12 hours as a shift at China) One client, 600T aluminum extrusion press with eexperiences workers, one piece of 6meters aluminum profiles, weight is 4g. The day output of aluminum extrusion profile is 5T~5.2T (24 hours).

Factors of aluminium extrusion press of create high output:

1. Good aluminium extrusion machine performance low failure;

2. Better temperature control for extrusion container, billet temperature, die temperature and so on;

3. Good aluminum billet quality;

4. Good extrusion die quality;

5. Experienced workers to operation (the process of normal building architecture aluminum profile is a little different from thin and small aluminum profile)

We have over ten years experienced of aluminium extrusion press manufacture, we can not only supply aluminium extrusion equipment, but also supply aluminium extrusion production process guidance.

The technical data of 600T aluminium extrusion press

1. Specification of aluminum billet: 80~100*460mm

2. Exit size: 110mm * 120mm

3. Total power: 77.6KW

4. Total weight: 25T

5. Overall size: 6000*3200*2600mm
