500T Aluminium Extrusion Press For Thin And Small Profiles


Hondda Machinery factory is a profession to produce 500T aluminium extrusion press for making the small and thin aluminum profile. For example, aluminium tile trim, wooden floor trim, stairs edge trim, door edge trim, and small aluminium profile for cupboard, cabinet, furniture and so on. Because these profiles function is decorative and no need to support any power, so these aluminum profile requests small and thin. But making these aluminum profiles require the aluminum extrusion press with high technology. If you use the big press and unsuitable pressure, the aluminum is easy to leak to the container or hard to get to shape. At the same time, big aluminum extrusion press is not good for energy saving.

Our 500T aluminium extrusion press is specializing in the production of small and thin aluminium profiles. We select the special pump, valve and electrical equipment and set the special pressure to make small and thin aluminum profile.
The characteristic is easy to operation, high efficiency, low failure, energy saving and high yield.

Now we focus on the aluminum extrusion press for reducing failure rate, increasing the extrusion speed, reducing the power consumption for energy saving and increase the product output for benefit client't profit.

The technical data of 500T aluminum extrusion press     .
1. Specification for aluminum billet: Φ 73~80 mm × 380 mm
2. Exit size of profile:  Φ100mm×L120mm
3. Specification for die base mold cavity: Φ 178 mm × 204 mm
4. Overall size:  5500mm×2300mm×2100 mm
5. Total power: 71 KW
6. Total weight: About 18 Tons
7. Hydraulic oil volume:1600 L (Viscosity : 300SUS AT 37℃)

The technical of other size of aluminium extrusion press

Welcome to visit our video of 500T aluminum extrusion press in running opertation:

http://youtu.be/FUm5FgUWTk4
